1、This product, as our latest design, not only has a good-looking appearance, but also has excellent working performance.
2、The appearance uses soft rubber as the handle material, which not only greatly improves the feel when used, but also more resistant to falling.
3.The upper cover is decorated with reflective materials, so that the whole is no longer monotonous. When working, the logo will emit a cool light (customizable LOGO, please contact customer service for details).
4、In terms of performance, the AP2-T06AT has three connection methods to suit different scenarios, and the one-button switching function greatly improves work efficiency.
The automatic storage function, even in the offline state, can automatically store the read barcodes in the memory, up to 16M of storage space, can store 100,000 barcodes at a time.
The megapixel CMOS sensor, with a scanning performance exceeding 90% of the scanners on the market, can read all types of barcodes, whether they are micro barcodes, or fuzzy, damaged, folded barcodes, which can be easily read.
Specification:
| Model | AP2-T06AT |
| Weight | 350g(without cable) |
| Size | 160 mm × 95 mm W × 60mm H |
| Cradle | 130 mm × 100 mm W × 65mm |
| Interface | USB |
| Light source | Illumination: white LED, Aiming; red LED, 525nm |
| Image sensor | 1280×800 CMOS |
| Processor | ARM32-bit |
| Resolution | 1D：≥3mil，2D：≥8.7mil @PCS90% |
| Depth of field | 3mil：55~100mm，13mil：55~350mm |
| Scan mode | Manual scanning, automatic induction scanning |
| Prompt | LED indicator light, buzzer, vibration |
| Scan angle | Roll：±360°,Pitch：±60°or greater,Yaw：±70°or greater） |
| Field of view | Horizontal 40°× Vertical 30° |
| Motion tolerance | 25cm/second |
| Power | DC5V(input),180mA(operating) |
| Print contrast | 25%PCS |
| Ambient light | 70000Lux |
| Wireless communication mode | Synchronous mode, storage mode |
| Transmission distance | 2.4GHz: 50 meters; Bluetooth: 10 meters（Open distance） |
| Storage capacity | 16Mb |
| Battery | 2600mAh |
| Charging time | About 5 hours |
| Continuous scanning time | ≥16hours |
| Standby time | ≥4 weeks |
| Supported barcodes |
1D: Codabar, Code39, Code32, Interleaved 2 of 5（ITF25）, Industrial 2 of 5, Matrix 2 of 5, Code93, Code11,Code128, Gs1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, ISBN, ISSN,GS1 databar, GS1 databar limited, GS1 databar expanded, ISBT, MSI, Febraban 2D: PDF417,Micro PD |
